85 Ton Truck Crane

85 Ton Truck Crane

Product Details:

  • Feature Truck Crane
  • Crane Type Truck
  • Application Construction, Hydro power, Railway, Material Yard, Storage Yard, Warehouse, Workshop, Factory, Outdoor Yard, Specified
  • Click to view more

Price And Quantity

  • 1 Piece

Product Specifications

  • Truck Crane
  • Truck
  • Construction, Hydro power, Railway, Material Yard, Storage Yard, Warehouse, Workshop, Factory, Outdoor Yard, Specified

Trade Information

  • Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Telegraphic Transfer (T/T), Western Union
  • 7-20 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Flat Rack Container, Fixing Product ON FR, Lifting Machine On Board, RORO Shipment
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India
  • CE, ISO, Gost, EPA(USA), CCC

Product Description

Owing to our rich knowledge in this domain, we are betrothed in offering optimum quality 85 Ton Truck Crane. The provided crane is extensively used in construction site as well as in airports for lifting items and objects. Offered crane is manufactured using superior grade components and cutting edge techniques at our advanced production set up. Apart from this, the offered 85 Ton Truck Crane is easily available in the market to our valued patrons.


  • Easy to operate
  • Sturdiness
  • Extended durability
  • Fine finish

85 Ton Truck Crane

Superior Performance

Powerful Lifting Capacity

The 85 ton truck crane has five-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 85t, full-extended boom length of 47m, jib length of 17.5m, max.lifting height including jib of 64.7m, reduce weight and improve safety significantly.

Jib mounting angles are 0o, 15o, and 30o, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.

Efficient & Unique Hydraulic System

Load feedback and constant power control is applied to provide strong lifting capacity and good micro-mobility. Unique steering buffer design is adopted to ensure stable braking operation.

Excellent Travelling Performance

Double-axle drive is used to provide good trafficability and comfortableness under complex road condition; all-wheel steering design with the third and fourth axles as auxiliary steering axle features small turning radius;

The pressure of outriggers could be displayed in control cab; engine has the multimode power output function, which reduces power consumption; the use of tipping over early-warning technology provides high stable and safe operation.

Safety and Stability

Intelligent Electronic Control

Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.

Technical specification

Max. lifting capacity


Overall length

14680 mm

Overall width

2750 mm

Overall height

4000 mm

Axle distance-1,2

1520 mm

Axle distance-2,3

4650 mm

Axle distance-3,4

1500 mm

Overall weight

46570 kg

Front axle load

21600 Kg

Rear axle load

24970 kg

Rated power

275 kW/2100 rpm

Rated torque

1550 N.m/1100~1400rpm

Max. traveling speed

80 km/h

Min.turning radius


Min.turning radius of boom head


Drive train


Min. ground clearance

300 mm

Approach angle


Departure angle


Max. Gradeability


Fuel consumption per 100km


Temperature range

-30oC- +60oC

Min.lifting radius

3 m

Tail swing radius of superstructure


Boom section


Boom shape


Max. lifting moment-Base boom


Max. lifting moment-Full-extend boom


Max. lifting moment-Full-extend boom+jib


Length-Base boom


Length-Full-extend boom

47 m

Length-Full-extend boom+jib

64.5 m

Outrigger span(Longitudinal/Transversal)

6.187.8 m

Jib offset

0o 15o 30o

Max. single rope lifting speed of main winch no

130 m/min

Max. single rope lifting speed of auxiliary

130 m/min

Full extend/retract time of boom

150 / 150 s

Full raise/lower time of boom

70/ 90 s

Swing speed

2.0 r/min

HVAC in up cab

Cooling and Heating

HVAC in low cab

Cooling and Heating
