160 Ton Truck Crane

Product Description

Superior Performance

Powerful Lifting Capacity

The 160 ton truck crane has six-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 160t, full-extended boom length of 63m, jib length of 36m, max.lifting height including jib of 99m, reducing weight and improving safety significantly.

Jib mounting angles are 0°, 20°, and 40°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.

Efficient & Unique Hydraulic System

Self-developed dual pump conversing / dividing main valve is used, with higher conversing efficiency for single-action and good dividing controllability for combined-action of dual pump;

Electro-proportional variable displacement piston pump is applied to ensure high-precision flow control, high efficiency and high energy-saving features.

Excellent Traveling Performance

5-Axle chassis with multiple braking modes are applied to provide good mobility. Trafficability and comfortableness under the complex road condition is improved with reliable traveling performance;

The use of tipping over early-warning technology guarantees high stable and safe operation.

Safety and Stability

Intelligent Electronic Control

Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.

The Load Moment Limiter

Equipped with the comprehensive intelligent protection system with accuracy within 5% and interlock control system, the 160 ton truck crane possesses more safe and reliable operation.

More Safe Devices

Main and auxiliary winches are equipped with over roll-out limiter to prevent over rolling-out of wire rope.

Boom and jib ends are equipped with height limiters respectively to prevent over-hoisting of wire rope.

Hydraulic system is configured with the balance valve, overflow valve and two-way hydraulic lock etc., to ensure stable and reliable operation.
