200 HP Motor Grader

200 HP Motor Grader

Product Details:


Price And Quantity

  • 1 Piece

Trade Information

  • Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Telegraphic Transfer (T/T), Western Union
  • 7-20 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Flat Rack Container, Fixing Product ON FR, Lifting Machine On Board, RORO Shipment
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India
  • CE, ISO, Gost, EPA(USA), CCC

Product Description

200 HP Motor Grader

Powerful Transmission

  • The 200 HP motor grader combines advantages of both hydraulic and mechanical transmission
  • Rear axle applies no-spin differential lock technology, enhancing synchronization
  • Large torque rotary motor and worm-gear case with overload protection provides the blade maximum power in ground leveling

Smart Operations

  • Automatic gears shift, easy to operate and highly efficient
  • Speed range and initial gear can be set by operator, making operating extremely easy
  • Intelligent reversing technology reduces the time to change direction

Safety and Comfort

  • The 200 HP motor grader features step-less speed change, low gear-shifting impact and comfortable operation
  • Joystick requires less exertion of physical force and less distance, which is able to realize synchronous actions
  • Fail proof triple braking system (travel braking, park braking and hydraulic system assistance braking) ensures safety and reliability

Convenient Maintenance

  • Wider cabin doors on both sides give way to more accessible maintenance
  • Electronic devices and filters are centrally positioned for convenient maintenance

Technical Specifications

Engine manufacturer


Rated power

146/1950 kW/rpm

Length-between front axle and rear axle

6229 mm


17.5-25 12PR

Hydraulic system tank

210 L

Fuel capacity

310 L

Length - front axle to mid-tandem

1538 mm

Engine model



Tier 2


960 N.m

Forward/Reverse gears

10 / 10

Speed forward

38 km/h

Speed reverse

38 km/h

Max. front wheel turning angle

50° / 50°

Max.front wheel tilt angle

17° / 17°

Max.oscillation angle of front axle

25° / 25°

Max.oscillation angle of tandem box


Min.turning radius

7.4 mm

Moldboard width x Arc radius

3660 x 620 mm

Max.blade position angle


Blade==Max.lift above ground

480 mm

Circle rotation


Operating weight (Standard)

15700 kg

Dimensions (Standard)

9254x2725x3260 mm
