3.5 Ton Mini Excavator

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

3.5 Ton Mini Excavator Price And Quantity

Minimum Order Quantity 1 Piece

3.5 Ton Mini Excavator Trade Information

Payment Terms Delivery Point (DP) Letter of Credit (L/C) Telegraphic Transfer (T/T) Western Union Days after Acceptance (DA)
Delivery Time 7-20 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Flat Rack Container, Fixing Product ON FR, Lifting Machine On Board, RORO Shipment
Main Export Market(s) Asia Australia North America Eastern Europe Middle East Africa Western Europe Central America South America
Main Domestic Market All India
Certifications CE, ISO, Gost, EPA(USA), CCC

Product Description

3.5 Ton Mini Excavator

3.5 Ton mini excavator is the best digging tool for landscape engineering and farmland improvement. Built with advanced technology and reliable components, the machine has the following features.

Good Controllability

Mature load sensing system commissioning technique provides superior experience in controllability.

Energy Saving and Environmental Friendly

The independently developed smart control system effects a perfect match between the engine and the main pump and makes operation more efficient at lower fuel cost.

Stable and Reliable

Reinforced work equipment and high strength slewing circle provide a more stable overall performance of the machine.

Safe and Comfortable

Standard canopy with newly designed damping system and multi level noise reduction design makes operation safer and more comfortable.

Engine model	Yanmar 3TNV88-BSSY
Rated power	28HP(20.4kW)/2200rpm
Max.torque	106 N.m/1200rpm
Displacement	1.642L
Emission standard	Tier 3
Operating weight	3780 kg
Max. digging height	4855mm
Max. dumping height	3460mm
Max. digging depth	3105mm
Max. vertical digging depth	2700mm
Max. digging reach	5465mm
Min. swing radius	2475mm
Height at min.swing radius	3685mm
Max.ground clearance of blade up	375mm
Max.depth of blade down	370mm
Transport length	4915mm
Transport width	1720mm
Transport height	2515mm
Upper width	1550mm
Blade height	350mm
Tail swing radius	860mm
Min. ground clearance	295mm
Std. track shoe width	300 mm
Bucket capacity	0.12 m³
Track gauge	1420mm
Boom length	2540 mm
Arm length	1400 mm
Travel speed	4.4/2.4km/h
Swing speed	9rpm
Gradeability	30°(58%)
Ground pressure	32kPa
Bucket digging force	30.4kN
Arm digging force	18.2kN
Fuel tank capacity	40L
Hydraulic tank capacity	40L
