2 Ton Mini Excavator

Request to Call Back Send Inquiry

2 Ton Mini Excavator Price And Quantity

Payment Terms Letter of Credit (L/C) Western Union Delivery Point (DP) Telegraphic Transfer (T/T) Days after Acceptance (DA)
Delivery Time 7-20 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Flat Rack Container, Fixing Product ON FR, Lifting Machine On Board, RORO Shipment
Main Export Market(s) North America Eastern Europe Western Europe Africa Central America Australia Middle East South America Asia
Main Domestic Market All India
Certifications CE, ISO, Gost, EPA(USA), CCC

2 Ton Mini Excavator

Energy Saving and Environment Friendly

YANMAR engine with optimized power matching technique effects high efficiency and low emission.

Safe and Comfortable

Standard canopy with newly-designed damping system and multi level noise reduction design makes operation safer and more comfortable.

Good Control ability

Control ability is optimized with the application of mature load sensing system and independently developed hydraulic commissioning technique.

Reliable and Stable

Reinforced and high strength work equipment provide better reliability. Extendable and retractable undercarriage imparts better stability while working on uneven surface.

Engine model	Yanmar 3TNV70
Rated power	13.8HP(10.3KW)/2200rpm
Max.torque	48.2-52.4 N.m/1600rpm
Displacement	0.854L
Emission standard	Tier 3
Operating weight	1850kg
Max. digging height	3665mm
Max. dumping height	2635mm
Max. digging depth	2360mm
Max. vertical digging depth	2215mm
Max. digging reach	4000mm
Min. swing radius	1655mm
Height at min.swing radius	2745mm
Max.ground clearance of blade up	310
Max.depth of blade down	320
Transport length	3575mm
Transport width	980mm/1350mm
Transport height	2420mm
Upper width	980mm
Blade height	270mm
Tail swing radius	920mm
Min. ground clearance	180mm
Std. track shoe width	230mm
Bucket capacity	0.05 m³
Track gauge	750mm/1120mm
Boom length	1810 mm
Arm length	1130 mm
Travel speed	3.7/2.1KM/h
Swing speed	10rpm
Grade ability	70%/35°
Ground pressure	29.1kpa
Bucket digging force	15.2KN
Arm digging force	9.2KN
Fuel tank capacity	20L
Hydraulic tank capacity	21L
