40 Ton Rough Terrain Crane
Product Details:
- Crane Type Other Cranes
- Application Ship Building Hydro power Railway Storage Yard Workshop Factory Specified Construction Warehouse Material Yard Outdoor Yard
- Click to View more
X
40 Ton Rough Terrain Crane Price And Quantity
- 1 Piece
40 Ton Rough Terrain Crane Product Specifications
- Other Cranes
- Ship Building Hydro power Railway Storage Yard Workshop Factory Specified Construction Warehouse Material Yard Outdoor Yard
40 Ton Rough Terrain Crane Trade Information
- Days after Acceptance (DA) Delivery Point (DP) Letter of Credit (L/C) Telegraphic Transfer (T/T) Western Union
- 7-20 Days
- Yes
- Contact us for information regarding our sample policy
- Flat Rack Container, Fixing Product ON FR, Lifting Machine On Board, RORO Shipment
- Western Europe Africa Central America Eastern Europe Australia Middle East South America Asia North America
- All India
- CE, ISO, Gost, EPA(USA), CCC
Product Description
40 Ton Rough Terrain Crane
Superior performance
Powerful lifting capacity
The 40 ton rough terrain crane features five-section boom made from strengthened steel and optimized U-shaped section with max.lifting capacity of 40t, full-extended boom length of 31.5m, max.tip height including jib of 47.4m, which reduces weight and significantly improve safety.
Jib mounting angles are 0°,15°, and 30° to allow quick change-overs between different operating conditions so as to improve working efficiency of the machine.
Adjustable hydraulic system
Hydraulic system load feedback and constant power control provide powerful lifting capacity and excellent mobility. The unique steering buffer design guarantees smooth braking.
Excellent traveling performance
Four-wheel drive with four steering modes provides excellent mobility and control in all terrains. The rough terrain crane can handle tight traffic and complex road conditions due to its min.turning radius of only 6.2m.
Safety and Stability
Intelligent electronic control
Self-developed controller SYMC special for engineering machinery is configured. The CAN-bus fully digital network control technology provides stable control signal, simple harness, and high reliability. It can provide feedback on data and monitor the working condition of whole crane in real-time.
The load moment limiter
The 40 ton rough terrain crane is configured with comprehensive intelligent protection system that achieves precision within 10%. The comprehensive logic and interlock control system ensures safe and reliable operation.
Technical Specifications
| Max. lifting capacity | 40 t |
| Overall length | 12150mm |
| Overall width | 2625 mm |
| Overall height | 3410 mm |
| Axle distance | 3720 mm |
| Overall weight | 32300 kg |
| Front axle load | 16640 kg |
| Rear axle load | 15660 kg |
| Rated power | 119 kW/ 2500 rpm |
| Rated torque | 732 N.m/ 1500 rpm |
| Max. traveling speed | 37 km/h |
| Min.turning radius | 12.2/6.2 m |
| Drive train | 4x4 |
| Min. ground clearance | 400 mm |
| Approach angle | 23.9 ° |
| Departure angle | 23.3 ° |
| Max. gradeability | 75% |
| Fuel consumption per 100km | ≤55 L |
| Temperature range | – 20 ℃ - + 46℃ |
| Min.lifting radius | 3.05 m |
| Tail swing radius of superstructure | 3.94 m |
| Boom section | 4 |
| Boom shape | U-shaped |
| Max. lifting moment-Base boom | 1195 kN·m |
| Max. lifting moment-Full-extend boom | 743 kN·m |
| Max. lifting moment-Full-extend boom+jib | 330 kN·m |
| Length-Base boom | 10 m |
| Length-Full-extend boom | 31.5 m |
| Length-Full-extend boom+jib | 46.2 m |
| Outrigger span(Longitudinal/Transversal) | 6.15 x 6.15 m |
| Jib offset | 0 ° 15 ° 30 ° |
| Max. single rope lifting speed of main winch(no load) | 140 m/min |
| Max. single rope lifting speed of auxiliary winch(no load) | 140 m/min |
| Full extend/retract time of boom | 55 / 39 s |
| Full raise/lower time of boom | 43 / 57 s |
| Swing speed | 2.7 r/min |
| HVAC in cab | Cooling/Heating & Cooling |
