38 Ton Large Excavator
Product Details:
X
38 Ton Large Excavator Price And Quantity
- 1 Piece
38 Ton Large Excavator Trade Information
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Western Union Delivery Point (DP) Days after Acceptance (DA)
- 7-20 Days
- Yes
- Contact us for information regarding our sample policy
- Flat Rack Container, Fixing Product ON FR, Lifting Machine On Board, RORO Shipment
- Asia Australia North America Eastern Europe Western Europe Africa Central America Middle East South America
- All India
- CE, ISO, Gost, EPA(USA), CCC
Product Description
38 Ton Large Excavator
High Efficiency and Low Consumption
Customized Power Control System
With dual-pump and dual-circuit constant power control system, the engine outputs strong operating force. Optimized performance of the engine reduces power loss. The engine is designed to work in four modes according to different working conditions.
Optimized Main Valve
The main valve with movement coordination improves boom and arm operating speed, boom-down regeneration, and bucket confluence performance. This enables the 38 ton large excavator higher operating efficiency.
High Reliability
Genuine Components
The plates welded on the two main beam of swing platform considerably improve the bending resistance performance. Track rollers, carrier rollers and idlers use seal in lubrication that enhances service life. The tri-grouser track shoe rolled with high-strengthened alloy ensures favorable contact, stability and durability.
Optimized Boom, Arm and Bucket
With optimized design, the boom and arm of the 38 ton large excavator provide considerable working range and depth on the occasion of ditching, excavating and common construction while maintaining powerful digging force. Standard bucket equipped with highly rigid steel sheet, tips and side cutters can serve a longer period.
Safety and Comfort
Adjustable and Safe Cab
The height of seat, the inclination of backrest, the height of armrest, the seat position and the headrest can all be adjusted as desired. And the sealing ring protects the inner cab from dust and rain. Equipped with thickened steel sheet, the cab roof is strong enough to handle any impact, which greatly improves safety.
Shock Absorbing
The silicone rubber shock absorber is fixed to the swing platform in six points, which minimizes shock from rough road conditions and unexpected impact. This considerably increases the cab stability and operator comfort.
Longer Control Levers
Base on humanized design, the control levers and joysticks are easy to reach from any position.
| Engine model | Isuzu AA-6HK1XQP |
| Rated power | 255.5HP(190.5KW)/2000RPM |
| Max. Torque | 872.8N.m@1700rpm |
| Displacement | 7.79L |
| Max. digging depth | 6780mm |
| Max. dumping height | 6790mm |
| Max. digging reach | 10405mm |
| Min. swing radius | 4465 |
| Transport length | 11350mm |
| Transport width | 3190mm |
| Transport height | 3600mm |
| Upper width | 3150mm |
| Cab height | 3320mm |
| Tail swing radius | 3380mm |
| Min. ground clearance | 550mm |
| Std. track shoe width | 600mm |
| Bucket capacity | 1.8m³GP |
| Track gauge | 2590mm |
| Travel speed | 5.5/3.5km/h |
| Swing speed | 9.5rpm |
| Gradeability | 70%/35° |
| Ground pressure | 63kPa |
| Tractive force | 320KN |
| Bucket digging force | 235KN |
| Arm digging force | 206KN |
| Fuel tank | 380L |
| Hyd tank | 340L |
| Engine oil | 36L |
